Wholesale Integrated Solar Street Light

DESC.:

Cost effective all in one solar energy street light, anodized lamp body, corrosion-resistant, Radar sensing technology control to reduce ineffective illumination, sensing distance >10 meters.

description

Parameters:

  • Solar Panel: Mono-crystalline Solar Panel
  • Lithium Battery: Wide choice from 64Wh to 640Wh
  • LED Efficacy: 150lm/W
  • Life Span: 15,000Hrs

Features:

  • High-purity national standard 6063 all aluminum lamp body prevents the lamp from rusting.
  • Patented product with a drawer-style replaceable battery structure, facilitating maintenance and replacement, significantly extending product lifespan.
  • Multiple mounting options with adjustable angles; installation angle can be freely adjusted based on geographical location to ensure maximum energy harvesting.
  • Imported high-efficiency mono-crystalline silicon solar panels for higher conversion efficiency.
Specification
Model No.: KKAIO20W KKAIO40W KKAIO60W KKAIO80W KKAIO100W KKAIO200W
LED : 20pcs 40pcs 60pcs 80pcs 100pcs 200pcs
LED Lumens: 150lm/W 150lm/W 150lm/W 150lm/W 150lm/W 150lm/W
CCT: 5,500K-6,000K 5,500K-6,000K 5,500K-6,000K 5,500K-6,000K 5,500K-6,000K 5,500K-6,000K
Solar Panel: Mono-crystalline Solar Panel
Solar Panel: 6V 20W 6V 25W 6V 35W 6V 45W 6V 55W 6V 75W
CRI: >80 >80 >80 >80 >80 >80
Battery: Lithium Iron Phosphate
64WH 112WH 160WH 208WH 320WH 640WH
Working Time: 2-3 Rainy Days Backup
Charge Time: 4- 6 Hrs
Control mode: Separate Dusk to Dawn Light TBCC Controller
Material: ABS Plastics Housing ABS Plastics Housing ABS Plastics Housing ABS Plastics Housing ABS Plastics Housing ABS Plastics Housing
Installation Height: 4-6M 5-8M
Housing Color: Grey Grey Grey Grey Grey Grey
Holder Dia: 60mm 60mm 60mm 60mm 60mm 60mm
IP Class: IP66 IP66 IP66 IP66 IP66 IP66
Beam Angle: 135°x75° 135°x75° 135°x75° 135°x75° 135°x75° 135°x75°
LED Life Span: ≥ 15,000Hrs ≥ 15,000Hrs ≥ 15,000Hrs ≥ 15,000Hrs ≥ 15,000Hrs ≥ 15,000Hrs
Warranty: 2 years 2 years 2 years 2 years 2 years 2 years
